Neumann TLM 50 Diaphragm Diameter, Phantom Voltage, Requires Phantom Power, Interfaces, Max Diameter, SPL/Self-Noise Ratio, Self-Noise. 19 properties. Comparisons. Similar objects.

Neumann TLM 50 [+]Compare [E]dit [H]istory

Object «Neumann TLM 50» was created due to

Electronics

Microphones

Add new object to «Neumann TLM 50» or move existing objects here.

Object «Neumann TLM 50» has attributes [Show empty attributes][Hide empty attributes]

Attribute	Value
Diaphragm Diameter	12 mm
Phantom Voltage	48.00 V
Requires Phantom Power	+
Interfaces	3-pin XLR male
Max Diameter	56 mm
SPL/Self-Noise Ratio	10.46
Self-Noise	13 dB
Sound Pressure Level (SPL)	136 dB
Impedance	50 Ohm
Diaphragm Gauge	5 micron
Length	145 mm
Filters	HPF @ 100Hz HPF @ 30Hz
Pads	-10dB
Range	30 - 20,000 Hz
Sensitivity	20 mV/Pa
Pickup Pattern	Omnidirectional
Brand	Neumann
Name	Neumann TLM 50
Weight	490 g
Capsule Diameter	Add
Includes Tube Power Supply	Add
Has Battery Compartment	Add
Battery compartment type	Add
