| Attribute | Value |
| General |
| Production from | 1958 year |
| Make | Harley-Davidson |
| Model | Harley-Davidson Sportster XLCH Ironhead |
| Category | Sport |
| Engine and transmission |
| Engine type | V2, four-stroke |
| Valves per cylinder | Add |
| Fuel system | Carburettor |
| Engine details | Add |
| Displacement | 883 cm³ |
| Power | 40.1 kw |
| Max RPM | Add |
| Fuel consumption | 5.88 l/100km |
| Cooling system | Air |
| Transmission type,final drive | Chain |
| Torque | Add |
| Bore | 76.2 mm |
| Stroke | 96.8 mm |
| Gearbox | 4-speed |
| Greenhouse gases | 136.4 CO2 g/km. (CO2 - Carbon dioxide emission) |
| Fuel control | Overhead Valves (OHV) |
| Emission details | Add |
| Driveline | Add |
| Ignition | Add |
| Clutch | Add |
| Lubrication system | Add |
| Compression | 9.0:1 |
| Exhaust system | Add |
| Chassis |
| Front suspension | Hydraulic telescopic fork |
| Rear suspension | Swing-arm, twin hydraulic shocks |
| Front brakes | Expanding brake (drum brake) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | Add |
| Frame type | Steel single downtube |
| Front tyre | 3.25-19 |
| Rear tyre | 3.25-19 |
| Seat | Add |
| Wheels | Wire spoked |
| Front wheel travel | Add |
| Rear wheel travel | Add |
| Trail | Add |
| Rake (fork angle) | Add |
| Other |
| Battery capacity | Add |
| Starter | Kick |
| Color options | Add |
| Carrying capacity | Add |
| Light | Add |
| Instruments | Add |
| Electrical Voltage | 12 V |
| Dimensions |
| Wheelbase | 1,448 mm |
| Kerb weight | Add |
| Dry weight | 222 kg |
| Power/weight ratio | 0.1804 |
| Overall height | Add |
| Overall length | Add |
| Overall width | Add |
| Seat height | Add |
| Alternate seat height | Add |
| Ground clearance | Add |
| Front percentage of weight | Add |
| Rear percentage of weight | Add |
| Performance |
| Top speed | Add |
| Acceleration 0-100 km/h | Add |
| Length | Add |
| Reserve fuel capacity | Add |
| Fuel capacity | 17 l |
| Oil capacity | 2.8 l |
| Width | Add |
| Height | Add |
