| Attribute | Value |
| General |
| Production from | 2012 year |
| Make | Hero |
| Model | Hero Splendor NXG |
| Category | Sport |
| Engine and transmission |
| Engine type | Single cylinder, four-stroke |
| Valves per cylinder | Add |
| Fuel system | Carburettor. Side Draft, Variable Venturi Type |
| Engine details | Add |
| Displacement | 97.5 cm³ |
| Power | 5.4 kw |
| Max RPM | Add |
| Fuel consumption | Add |
| Cooling system | Air |
| Transmission type,final drive | Chain |
| Torque | 8 Nm |
| Bore | 50 mm |
| Stroke | 49.5 mm |
| Gearbox | 4-speed |
| Greenhouse gases | Add |
| Fuel control | Overhead Cams (OHC) |
| Emission details | Add |
| Driveline | Constant mesh |
| Ignition | Digital CDI |
| Clutch | Wet, multidisk |
| Lubrication system | Add |
| Compression | 9.0:1 |
| Exhaust system | Add |
| Chassis |
| Front suspension | Telescopic hydraulic shock absorbers |
| Rear suspension | Swing arm with hydraulic shock absorbers |
| Front brakes | Expanding brake (drum brake) |
| Rear brakes | Expanding brake (drum brake) |
| Diameter | 110 mm |
| Frame type | Tubular double cradle |
| Front tyre | 2.75-18 |
| Rear tyre | 2.75-18 |
| Seat | Add |
| Wheels | Black, 5-spoke. |
| Front wheel travel | Add |
| Rear wheel travel | Add |
| Trail | Add |
| Rake (fork angle) | Add |
| Performance |
| Top speed | Add |
| Other |
| Starter | Kick |
| Color options | - black w/purple stripes
- black w/silver stripes
- blue
- red
- silver
|
| Carrying capacity | Add |
| Light | 12V 35W/35W halogen headlight |
| Instruments | Add |
| Electrical Voltage | 12 V |
| Dimensions |
| Wheelbase | Add |
| Kerb weight | 109 kg |
| Dry weight | Add |
| Power/weight ratio | Add |
| Overall height | 1,095 mm |
| Overall length | 1,965 mm |
| Overall width | 720 mm |
| Seat height | 785 mm |
| Alternate seat height | Add |
| Ground clearance | 160 mm |
| Front percentage of weight | Add |
| Rear percentage of weight | Add |
| Acceleration 0-100 km/h | Add |
| Length | Add |
| Width | Add |
| Reserve fuel capacity | 1.8 l |
| Fuel capacity | 9.5 l |
| Oil capacity | Add |
| Height | Add |
| Battery capacity | 3 Ah |
