| Attribute | Value |
| General |
| Production from | 2015 year |
| Make | Quadro |
| Model | Quadro 3 |
| Category | Scooter |
| Engine and transmission |
| Engine type | Single cylinder, four-stroke |
| Valves per cylinder | Add |
| Fuel system | Carburettor |
| Engine details | Add |
| Displacement | 346 cm³ |
| Power | 19.7 kw |
| Max RPM | Add |
| Fuel consumption | Add |
| Cooling system | Liquid |
| Transmission type,final drive | Belt |
| Torque | 28.8 Nm |
| Bore | Add |
| Stroke | Add |
| Gearbox | Automatic |
| Greenhouse gases | Add |
| Fuel control | Single Overhead Cams (SOHC) |
| Emission details | Euro 3 |
| Driveline | Add |
| Ignition | Electronic |
| Clutch | Automatic dry centrifugal |
| Lubrication system | With wet-sump pressurized pump |
| Compression | Add |
| Exhaust system | Add |
| Chassis |
| Front suspension | HTS system (oleo-pneumatic tilting suspension) |
| Rear suspension | Dual dumpers - wheel travel of 100 mm |
| Front brakes | Single disc. Hydraulic. |
| Rear brakes | Single disc. Hydraulic. |
| Diameter | 256 mm |
| Frame type | Steel tubes |
| Front tyre | 110/80-14 |
| Rear tyre | 140/70-15 |
| Seat | Add |
| Wheels | #ffffff;in.)The spring season opens with the arrival of the new |
| Front wheel travel | Add |
| Rear wheel travel | 100 mm |
| Trail | Add |
| Rake (fork angle) | 19 degree |
| Other |
| Battery capacity | Add |
| Starter | Electric |
| Color options | |
| Carrying capacity | Add |
| Light | Add |
| Instruments | Add |
| Electrical Voltage | 12 V |
| Dimensions |
| Wheelbase | Add |
| Kerb weight | Add |
| Dry weight | 200 kg |
| Power/weight ratio | 0.0985 |
| Overall height | Add |
| Overall length | 2,270 mm |
| Overall width | 811 mm |
| Seat height | 780 mm |
| Alternate seat height | Add |
| Ground clearance | Add |
| Front percentage of weight | Add |
| Rear percentage of weight | Add |
| Performance |
| Top speed | Add |
| Acceleration 0-100 km/h | Add |
| Length | Add |
| Reserve fuel capacity | Add |
| Fuel capacity | 13 l |
| Oil capacity | Add |
| Width | Add |
| Height | Add |
