| Attribute | Value |
| General |
| Production from | 2006 year |
| Make | Yamaha |
| Model | Yamaha YZ 125 |
| Category | Cross / motocross |
| Engine and transmission |
| Engine type | V2, four-stroke |
| Valves per cylinder | Add |
| Fuel system | Carburettor. Mikuni TMX38 |
| Engine details | Add |
| Displacement | 124 cm³ |
| Power | Add |
| Max RPM | Add |
| Fuel consumption | Add |
| Cooling system | Liquid |
| Transmission type,final drive | Chain |
| Torque | Add |
| Bore | 54 mm |
| Stroke | 54.5 mm |
| Gearbox | 5-speed |
| Greenhouse gases | Add |
| Fuel control | Add |
| Emission details | Add |
| Driveline | Add |
| Ignition | CDI |
| Clutch | Wet, multiple-disc |
| Lubrication system | Premix |
| Compression | 8.6:1 |
| Exhaust system | Add |
| Chassis |
| Front suspension | Telescopic fork |
| Rear suspension | Swinging arm (link-type monocross) |
| Front brakes | Single disc |
| Rear brakes | Single disc |
| Diameter | 245 mm |
| Frame type | Add |
| Front tyre | 80/90-M21 |
| Rear tyre | 100/90-M19 |
| Seat | Add |
| Wheels | Add |
| Front wheel travel | 300 mm |
| Rear wheel travel | 125 mm |
| Trail | Add |
| Rake (fork angle) | Add |
| Other |
| Battery capacity | Add |
| Starter | Kick |
| Color options | Add |
| Carrying capacity | Add |
| Light | Add |
| Instruments | Add |
| Electrical Voltage | Add |
| Dimensions |
| Wheelbase | 1,443 mm |
| Kerb weight | Add |
| Dry weight | 86 kg |
| Power/weight ratio | Add |
| Overall height | 1,318 mm |
| Overall length | 2,139 mm |
| Overall width | 827 mm |
| Seat height | 998 mm |
| Alternate seat height | Add |
| Ground clearance | 388 mm |
| Front percentage of weight | Add |
| Rear percentage of weight | Add |
| Performance |
| Top speed | Add |
| Acceleration 0-100 km/h | Add |
| Length | Add |
| Reserve fuel capacity | Add |
| Fuel capacity | 8 l |
| Oil capacity | Add |
| Width | Add |
| Height | Add |
