Bell 230 [+]Compare [E]dit [H]istory
Object «Bell 230» was created due to
Add new object to «Bell 230» or move existing objects here.
Object «Bell 230» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Bell Helicopter |
| Model | Bell 230 |
| Country | United States |
| Manufactured from | 1990 year |
| Manufactured to | 1995 year |
| Type | Mid Size Helicopters |
| Icao | B230 |
| Performance | |
| Engine | 2x Allison 250-C30G2 |
| Power, hp | 700 hp |
| Power, lbf | Add |
| Avionics | Add |
| Max cruise speed | 259 km/h |
| Approach speed | Add |
| Travel range | 700 km |
| Fuel economy | Add |
| Service ceiling | 4,724 m |
| Rate of climb | 8.13 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 3,810 kg |
| Max landing weight | Add |
| Max payload | 1,000 kg |
| Fuel tank capacity | 931 l |
| Baggage volume | 1 m³ |
| Dimensions | |
| Seats | 1 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.3 m |
| Cabin width | 1.4 m |
| Cabin length | 2.1 m |
| Exterior length | 15.3 m |
| Tail height | 3.6 m |
| Fuselage diameter | 1.55 m |
| Wing span | 12.8 m |
| Wing tips | No Winglets |
