Object «Bell 412» has attributes

Attribute Value
General
Manufacturer Bell Helicopter
Model Bell 412
Country United States
Manufactured from 1981 year
Manufactured to Add
Type Large Helicopters
Icao B412
Performance
Engine 1x 1 × Pratt & Whitney Canada PT6T-3D Twin-Pac
Power, hp 1,250 hp
Power, lbf Add
Avionics Garmin GTN-750 NAV/COM/WAAS GPS, Helicopter Terrain Avoidance Warning System (H-TAWS) Capability
Max cruise speed 230 km/h
Approach speed Add
Travel range 659 km
Fuel economy 0.612 km/l
Service ceiling 6,096 m
Rate of climb 6.86 m/sec
Take off distance Add
Landing distance Add
Weights
Max take off weight 5,398 kg
Max landing weight Add
Max payload 2,190 kg
Fuel tank capacity 1,253 l
Baggage volume 0.8 m³
Dimensions
Seats 15
Seats - business class Add
Seats - first class Add
Cabin height 1.24 m
Cabin width 2.43 m
Cabin length 2.34 m
Exterior length 17.02 m
Tail height 4.54 m
Fuselage diameter 2.6 m
Wing span 14.02 m
Wing tips No Winglets
