Bell 47J Ranger [+]Compare [E]dit [H]istory
Object «Bell 47J Ranger» was created due to
Add new object to «Bell 47J Ranger» or move existing objects here.
Object «Bell 47J Ranger» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Bell Helicopter |
| Model | Bell 47J Ranger |
| Country | United States |
| Manufactured from | 1956 year |
| Manufactured to | 1962 year |
| Type | Light Helicopters |
| Icao | B47J |
| Performance | |
| Engine | 1x Lycoming VO-435-A1B |
| Power, hp | 260 hp |
| Power, lbf | Add |
| Avionics | Add |
| Max cruise speed | 167 km/h |
| Approach speed | Add |
| Travel range | 415 km |
| Fuel economy | Add |
| Service ceiling | 3,353 m |
| Rate of climb | 4.42 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 1,270 kg |
| Max landing weight | Add |
| Max payload | 283 kg |
| Fuel tank capacity | 182 l |
| Baggage volume | 0.4 m³ |
| Dimensions | |
| Seats | 4 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | Add |
| Cabin width | Add |
| Cabin length | Add |
| Exterior length | 9.87 m |
| Tail height | 2.8 m |
| Fuselage diameter | 1.5 m |
| Wing span | 11.3 m |
| Wing tips | No Winglets |
