Curtiss SB2C Helldiver [+]Compare [E]dit [H]istory
Object «Curtiss SB2C Helldiver» was created due to
Add new object to «Curtiss SB2C Helldiver» or move existing objects here.
Object «Curtiss SB2C Helldiver» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Curtiss |
| Model | Curtiss SB2C Helldiver |
| Country | United States |
| Manufactured from | 1942 year |
| Manufactured to | 1945 year |
| Type | Military Propellor Planes |
| Icao | SB2C |
| Performance | |
| Engine | 1x Wright R-2600-20 Twin Cyclone |
| Power, hp | 1,900 hp |
| Power, lbf | Add |
| Avionics | Add |
| Max cruise speed | 474 km/h |
| Approach speed | 143 km/h |
| Travel range | 1,874 km |
| Fuel economy | Add |
| Service ceiling | 8,870 m |
| Rate of climb | 9.14 m/sec |
| Take off distance | 178 m |
| Landing distance | Add |
| Weights | |
| Max take off weight | 7,710 kg |
| Max landing weight | 7,537 kg |
| Max payload | 1,500 kg |
| Fuel tank capacity | 1,344 l |
| Baggage volume | Add |
| Dimensions | |
| Seats | 2 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | Add |
| Cabin width | Add |
| Cabin length | Add |
| Exterior length | 11.18 m |
| Tail height | 5.16 m |
| Fuselage diameter | 1.4 m |
| Wing span | 15.16 m |
| Wing tips | No Winglets |
