Eclipse 500 [+]Compare [E]dit [H]istory
Object «Eclipse 500» was created due to
Add new object to «Eclipse 500» or move existing objects here.
Object «Eclipse 500» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Eclipse Aviation |
| Model | Eclipse 500 |
| Country | United States |
| Manufactured from | 2006 year |
| Manufactured to | 2008 year |
| Type | VLJ (Very Light Jets) |
| Icao | EA50 |
| Performance | |
| Engine | 2x Pratt & Whitney PW610F turbofan |
| Power, hp | Add |
| Power, lbf | 900 lbf |
| Avionics | Avio Next Generation |
| Max cruise speed | 685 km/h |
| Approach speed | 128 km/h |
| Travel range | 2,084 km |
| Fuel economy | 5.157 km/l |
| Service ceiling | 12,497 m |
| Rate of climb | 16.84 m/sec |
| Take off distance | 715 m |
| Landing distance | 686 m |
| Weights | |
| Max take off weight | 2,612 kg |
| Max landing weight | 2,456 kg |
| Max payload | 1,027 kg |
| Fuel tank capacity | 700 l |
| Baggage volume | 0.45 m³ |
| Dimensions | |
| Seats | 6 |
| Seats - business class | 4 |
| Seats - first class | Add |
| Cabin height | 1.27 m |
| Cabin width | 1.42 m |
| Cabin length | 3.75 m |
| Exterior length | 10.1 m |
| Tail height | 3.35 m |
| Fuselage diameter | 1.47 m |
| Wing span | 11.4 m |
| Wing tips | No Winglets |
