Eurocopter EC145 [+]Compare [E]dit [H]istory
Object «Eurocopter EC145» was created due to
Add new object to «Eurocopter EC145» or move existing objects here.
Object «Eurocopter EC145» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Eurocopter |
| Model | Eurocopter EC145 |
| Country | France |
| Manufactured from | 1999 year |
| Manufactured to | Add |
| Type | Mid Size Helicopters |
| Icao | EC45 |
| Performance | |
| Engine | 2x Turbomeca Arriel 1E2 turboshafts |
| Power, hp | 740 hp |
| Power, lbf | Add |
| Avionics | Thales Avionics MEGHAS Flight Control Display System, FADEC |
| Max cruise speed | 246 km/h |
| Approach speed | Add |
| Travel range | 689 km |
| Fuel economy | 1.023 km/l |
| Service ceiling | 5,243 m |
| Rate of climb | 8.13 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 3,585 kg |
| Max landing weight | Add |
| Max payload | 1,793 kg |
| Fuel tank capacity | 867 l |
| Baggage volume | 1.32 m³ |
| Dimensions | |
| Seats | 11 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.27 m |
| Cabin width | 1.55 m |
| Cabin length | 3.42 m |
| Exterior length | 13.03 m |
| Tail height | 3.96 m |
| Fuselage diameter | 1.73 m |
| Wing span | 11 m |
| Wing tips | No Winglets |
