Eurocopter Super Puma EC225 [+]Compare [E]dit [H]istory
Object «Eurocopter Super Puma EC225» was created due to
Add new object to «Eurocopter Super Puma EC225» or move existing objects here.
Object «Eurocopter Super Puma EC225» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Eurocopter |
| Model | Eurocopter Super Puma EC225 |
| Country | France |
| Manufactured from | 2004 year |
| Manufactured to | Add |
| Type | Large Helicopters |
| Icao | EC25 |
| Performance | |
| Engine | 2x 2 × Turbomeca Makila 2A1 turboshafts |
| Power, hp | 2,411 hp |
| Power, lbf | Add |
| Avionics | DF935 (Chelton), Flight Management System CMA9000, ATC Transponder TDR94 |
| Max cruise speed | 278 km/h |
| Approach speed | Add |
| Travel range | 985 km |
| Fuel economy | 0.435 km/l |
| Service ceiling | 6,096 m |
| Rate of climb | 8.69 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 11,200 kg |
| Max landing weight | Add |
| Max payload | 5,765 kg |
| Fuel tank capacity | 2,771 l |
| Baggage volume | 3 m³ |
| Dimensions | |
| Seats | 24 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.45 m |
| Cabin width | 1.8 m |
| Cabin length | 7.87 m |
| Exterior length | 19.5 m |
| Tail height | 4.97 m |
| Fuselage diameter | 2 m |
| Wing span | 16.2 m |
| Wing tips | No Winglets |
