Object «Grumman F-14 Tomcat» has attributes

Attribute Value
General
Manufacturer Grumman
Model Grumman F-14 Tomcat
Country United States
Manufactured from 1969 year
Manufactured to 1991 year
Type Fighter Jets
Icao F14
Performance
Engine 2x General Electric F110-GE-400
Power, hp Add
Power, lbf 27,800 lbf
Avionics Hughes AN/AWG-9, AN/ALR-23, Raytheon AN/APG-71
Max cruise speed 2,485 km/h
Approach speed 232 km/h
Travel range 2,963 km
Fuel economy 0.382 km/l
Service ceiling 17,069 m
Rate of climb 228.6 m/sec
Take off distance 762 m
Landing distance 732 m
Weights
Max take off weight 33,725 kg
Max landing weight Add
Max payload 6,600 kg
Fuel tank capacity 11,299 l
Baggage volume Add
Dimensions
Seats 2
Seats - business class Add
Seats - first class Add
Cabin height Add
Cabin width Add
Cabin length Add
Exterior length 19.1 m
Tail height 4.9 m
Fuselage diameter Add
Wing span 19.55 m
Wing tips No Winglets
