Kamov Ka-27 “Helix” [+]Compare [E]dit [H]istory
Object «Kamov Ka-27 “Helix”» was created due to
Add new object to «Kamov Ka-27 “Helix”» or move existing objects here.
Object «Kamov Ka-27 “Helix”» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Kamov |
| Model | Kamov Ka-27 “Helix” |
| Country | Russia |
| Manufactured from | 1982 year |
| Manufactured to | Add |
| Type | Military Helicopters |
| Icao | KA27 |
| Performance | |
| Engine | 2x 2 × Isotov TV3-117V turboshaft engines |
| Power, hp | 2,230 hp |
| Power, lbf | Add |
| Avionics | Add |
| Max cruise speed | 206 km/h |
| Approach speed | Add |
| Travel range | 982 km |
| Fuel economy | 0.426 km/l |
| Service ceiling | 4,999 m |
| Rate of climb | 12.5 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 12,000 kg |
| Max landing weight | Add |
| Max payload | 4,000 kg |
| Fuel tank capacity | 2,650 l |
| Baggage volume | Add |
| Dimensions | |
| Seats | 6 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.24 m |
| Cabin width | 1.3 m |
| Cabin length | 4.52 m |
| Exterior length | 11.3 m |
| Tail height | 5.5 m |
| Fuselage diameter | 1.5 m |
| Wing span | 15.8 m |
| Wing tips | No Winglets |
