MD 500E [+]Compare [E]dit [H]istory
Object «MD 500E» was created due to
Add new object to «MD 500E» or move existing objects here.
Object «MD 500E» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | MD Helicopters |
| Model | MD 500E |
| Country | United States |
| Manufactured from | 1985 year |
| Manufactured to | Add |
| Type | Light Helicopters |
| Icao | H500 |
| Performance | |
| Engine | 1x 1× Allison 250-C20 Turboshaft |
| Power, hp | 420 hp |
| Power, lbf | Add |
| Avionics | Garmin Avionics |
| Max cruise speed | 250 km/h |
| Approach speed | Add |
| Travel range | 537 km |
| Fuel economy | 2.886 km/l |
| Service ceiling | 4,877 m |
| Rate of climb | 8.64 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 1,361 kg |
| Max landing weight | Add |
| Max payload | 689 kg |
| Fuel tank capacity | 242 l |
| Baggage volume | 1 m³ |
| Dimensions | |
| Seats | 5 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.52 m |
| Cabin width | 1.34 m |
| Cabin length | 2.44 m |
| Exterior length | 9.4 m |
| Tail height | 2.7 m |
| Fuselage diameter | 1.5 m |
| Wing span | 8.06 m |
| Wing tips | No Winglets |
