Object «MD Explorer» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | MD Helicopters |
| Model | MD Explorer |
| Country | United States |
| Manufactured from | 1992 year |
| Manufactured to | Add |
| Type | Mid Size Helicopters |
| Icao | EXPL |
| Performance | |
| Engine | 2x 2 × Pratt & Whitney PW207E turboshafts |
| Power, hp | 550 hp |
| Power, lbf | Add |
| Avionics | Digital avionics including FADEC |
| Max cruise speed | 250 km/h |
| Approach speed | Add |
| Travel range | 693 km |
| Fuel economy | 1.15 km/l |
| Service ceiling | 5,334 m |
| Rate of climb | 10.5 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 3,130 kg |
| Max landing weight | Add |
| Max payload | 1,417 kg |
| Fuel tank capacity | 602 l |
| Baggage volume | Add |
| Dimensions | |
| Seats | 6 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.24 m |
| Cabin width | 1.45 m |
| Cabin length | 1.91 m |
| Exterior length | 11.38 m |
| Tail height | 3.66 m |
| Fuselage diameter | 1.7 m |
| Wing span | 10.3 m |
| Wing tips | No Winglets |
