Object «Sikorsky CH-53E Super Stallion» has attributes

Attribute Value
General
Manufacturer Sikorsky Helicopter
Model Sikorsky CH-53E Super Stallion
Country United States
Manufactured from 1981 year
Manufactured to 2003 year
Type Military Helicopters
Icao H53S
Performance
Engine 3x 3 × General Electric T64-GE-416/ GE-416A / GE-419
Power, hp 4,380 hp
Power, lbf Add
Avionics Rockwell Collins Avionics
Max cruise speed 278 km/h
Approach speed Add
Travel range 1,000 km
Fuel economy 0.245 km/l
Service ceiling 5,639 m
Rate of climb 12.7 m/sec
Take off distance Add
Landing distance Add
Weights
Max take off weight 33,340 kg
Max landing weight Add
Max payload 14,515 kg
Fuel tank capacity 10,637 l
Baggage volume Add
Dimensions
Seats 55
Seats - business class Add
Seats - first class Add
Cabin height 1.98 m
Cabin width 2.29 m
Cabin length 9.14 m
Exterior length 30.2 m
Tail height 8.46 m
Fuselage diameter 2.5 m
Wing span 24.08 m
Wing tips No Winglets
