Attribute | Value |
---|---|
General | |
Manufacturer | Sukhoi |
Model | Sukhoi/Beriev Be-103 “Snipe” |
Country | Russia |
Manufactured from | 2003 year |
Manufactured to | Add |
Type | Amphibious |
Icao | B103 |
Performance | |
Engine | 2x 2 × Continental IO-360-ES4 fuel-injected Horizontally flat engines |
Power, hp | 210 hp |
Power, lbf | Add |
Avionics | Avidyne Entegra |
Max cruise speed | 241 km/h |
Approach speed | 115 km/h |
Travel range | 852 km |
Fuel economy | 2.5 km/l |
Service ceiling | 4,999 m |
Rate of climb | 0.06 m/sec |
Take off distance | 340 m |
Landing distance | 460 m |
Weights | |
Max take off weight | 2,270 kg |
Max landing weight | Add |
Max payload | 380 kg |
Fuel tank capacity | 341 l |
Baggage volume | 0.31 m³ |
Dimensions | |
Seats | 5 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 1.23 m |
Cabin width | 1.25 m |
Cabin length | 3.2 m |
Exterior length | 10.65 m |
Tail height | 3.76 m |
Fuselage diameter | 1.35 m |
Wing span | 12.72 m |
Wing tips | No Winglets |
