Sukhoi/Beriev Be-103 “Snipe” [+]Compare [E]dit [H]istory
Object «Sukhoi/Beriev Be-103 “Snipe”» was created due to
Add new object to «Sukhoi/Beriev Be-103 “Snipe”» or move existing objects here.
Object «Sukhoi/Beriev Be-103 “Snipe”» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Sukhoi |
| Model | Sukhoi/Beriev Be-103 “Snipe” |
| Country | Russia |
| Manufactured from | 2003 year |
| Manufactured to | Add |
| Type | Amphibious |
| Icao | B103 |
| Performance | |
| Engine | 2x 2 × Continental IO-360-ES4 fuel-injected Horizontally flat engines |
| Power, hp | 210 hp |
| Power, lbf | Add |
| Avionics | Avidyne Entegra |
| Max cruise speed | 241 km/h |
| Approach speed | 115 km/h |
| Travel range | 852 km |
| Fuel economy | 2.5 km/l |
| Service ceiling | 4,999 m |
| Rate of climb | 0.06 m/sec |
| Take off distance | 340 m |
| Landing distance | 460 m |
| Weights | |
| Max take off weight | 2,270 kg |
| Max landing weight | Add |
| Max payload | 380 kg |
| Fuel tank capacity | 341 l |
| Baggage volume | 0.31 m³ |
| Dimensions | |
| Seats | 5 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.23 m |
| Cabin width | 1.25 m |
| Cabin length | 3.2 m |
| Exterior length | 10.65 m |
| Tail height | 3.76 m |
| Fuselage diameter | 1.35 m |
| Wing span | 12.72 m |
| Wing tips | No Winglets |
