AKG Acoustics P220 Capsule Diameter, Phantom Voltage, Requires Phantom Power, Interfaces, Max Diameter, SPL/Self-Noise Ratio, Self-Noise. 18 properties. Comparisons. Similar objects.

AKG Acoustics P220 [+]Compare [E]dit [H]istory

Object «AKG Acoustics P220» was created due to

Electronics

Microphones

Add new object to «AKG Acoustics P220» or move existing objects here.

Object «AKG Acoustics P220» has attributes [Show empty attributes][Hide empty attributes]

Attribute	Value
Capsule Diameter	34 mm
Phantom Voltage	48.00 V
Requires Phantom Power	+
Interfaces	3-pin XLR male
Max Diameter	53 mm
SPL/Self-Noise Ratio	9.69
Self-Noise	16 dB
Sound Pressure Level (SPL)	155 dB
Diaphragm Diameter	26.7 mm
Length	165 mm
Filters	HPF: -12dB/octave @ 300Hz
Pads	-20dB
Range	40 - 20,000 Hz
Sensitivity	20 mV/Pa
Pickup Pattern	Cardioid
Brand	AKG Acoustics
Name	AKG Acoustics P220
Weight	525 g
Diaphragm Gauge	Add
Impedance	Add
Includes Tube Power Supply	Add
Has Battery Compartment	Add
Battery compartment type	Add
