| Attribute | Value |
| General |
| Production from | 2011 year |
| Make | Erik Buell Racing |
| Model | Erik Buell Racing 1125RR ASB |
| Category | Sport |
| Engine and transmission |
| Engine type | V2, four-stroke |
| Valves per cylinder | 4 |
| Fuel system | Injection |
| Engine details | 72 and #730; V-Twin. Titanium valves, 42.0mm intake, 35.4 mm exhaust |
| Displacement | 1,126 cm³ |
| Power | 124.1 kw |
| Max RPM | Add |
| Fuel consumption | Add |
| Cooling system | Add |
| Transmission type,final drive | Chain |
| Torque | 116.6 Nm |
| Bore | 103 mm |
| Stroke | 67.5 mm |
| Gearbox | 6-speed |
| Greenhouse gases | Add |
| Fuel control | Double Overhead Cams/Twin Cam (DOHC) |
| Emission details | Add |
| Driveline | 520 Chain. Primary drive: Straight cut gear, 1.806 ratio. |
| Ignition | Add |
| Clutch | Multiplate Mechanical Slipper |
| Lubrication system | Add |
| Compression | 14.3:1 |
| Exhaust system | Stainless steel ultralight 2 into 1 system. |
| Chassis |
| Front suspension | Showa Race 43mm inverted fork, fully adjustable with BPF technology providing true separation of rebound and compression damping. |
| Rear suspension | Light alloy swingarm with Showa Race damper, adjustable compression, rebound and ride height. |
| Front brakes | Double disc. Semi floating ISO multi-fin rotor with 8 piston ZTL2 caliper |
| Rear brakes | Single disc. Lightweight disc, 2 piston caliper |
| Diameter | 205 mm |
| Frame type | Light alloy large section beam with integral fuel cell. Subframe: Light alloy tubular. |
| Front tyre | 120/70-ZR17 |
| Rear tyre | 190/55-ZR17 |
| Seat | Add |
| Wheels | Front 6 spoke ZTL magnesium, 3.50 x 17. Rear 6 spoke magnesium, 6.00 x 17. |
| Front wheel travel | 120 mm |
| Rear wheel travel | 127 mm |
| Trail | Add |
| Rake (fork angle) | 21 degree |
| Other |
| Battery capacity | Add |
| Starter | Add |
| Color options | |
| Carrying capacity | Add |
| Light | Add |
| Instruments | Add |
| Electrical Voltage | Add |
| Dimensions |
| Wheelbase | 1,400 mm |
| Kerb weight | Add |
| Dry weight | 166 kg |
| Power/weight ratio | 0.7436 |
| Overall height | Add |
| Overall length | Add |
| Overall width | Add |
| Seat height | Add |
| Alternate seat height | Add |
| Ground clearance | Add |
| Front percentage of weight | Add |
| Rear percentage of weight | Add |
| Performance |
| Top speed | Add |
| Acceleration 0-100 km/h | Add |
| Length | Add |
| Reserve fuel capacity | Add |
| Fuel capacity | 17.41 l |
| Oil capacity | Add |
| Width | Add |
| Height | Add |
