Attribute | Value |
---|---|
General | |
Manufacturer | Douglas Aircraft Co. |
Model | Douglas C-47 Skytrain |
Country | United States |
Manufactured from | 1940 year |
Manufactured to | 1945 year |
Type | Military Transport Planes |
Icao | C47 |
Performance | |
Engine | 2x Pratt & Whitney R-1830-90C Twin Wasp |
Power, hp | 1,200 hp |
Power, lbf | Add |
Avionics | Add |
Max cruise speed | 370 km/h |
Approach speed | Add |
Travel range | 3,334 km |
Fuel economy | Add |
Service ceiling | 7,315 m |
Rate of climb | 5.74 m/sec |
Take off distance | Add |
Landing distance | Add |
Weights | |
Max take off weight | 14,061 kg |
Max landing weight | 12,227 kg |
Max payload | 2,721 kg |
Fuel tank capacity | 3,339 l |
Baggage volume | Add |
Dimensions | |
Seats | 32 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 1.5 m |
Cabin width | 1.7 m |
Cabin length | 9.1 m |
Exterior length | 19.4 m |
Tail height | 4.1 m |
Fuselage diameter | 2 m |
Wing span | 29.1 m |
Wing tips | No Winglets |
