Attribute | Value |
---|---|
General | |
Manufacturer | Grumman |
Model | Grumman HU-16 Albatross |
Country | United States |
Manufactured from | 1949 year |
Manufactured to | 1961 year |
Type | Amphibious |
Icao | U16 |
Performance | |
Engine | 2x Wright R-1820-76 Cyclone 9 |
Power, hp | 1,425 hp |
Power, lbf | Add |
Avionics | Add |
Max cruise speed | 380 km/h |
Approach speed | 130 km/h |
Travel range | 4,593 km |
Fuel economy | 0.724 km/l |
Service ceiling | 6,553 m |
Rate of climb | 7.37 m/sec |
Take off distance | 762 m |
Landing distance | 410 m |
Weights | |
Max take off weight | 17,010 kg |
Max landing weight | 14,965 kg |
Max payload | 4,535 kg |
Fuel tank capacity | 6,469 l |
Baggage volume | Add |
Dimensions | |
Seats | 3 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 1.93 m |
Cabin width | 2.28 m |
Cabin length | 7.98 m |
Exterior length | 19.16 m |
Tail height | 7.87 m |
Fuselage diameter | 2.4 m |
Wing span | 29.46 m |
Wing tips | No Winglets |
