Attribute | Value |
---|---|
General | |
Manufacturer | Curtiss |
Model | Curtiss C-46 Commando |
Country | United States |
Manufactured from | 1940 year |
Manufactured to | 1945 year |
Type | Military Transport Planes |
Icao | C46 |
Performance | |
Engine | 2x Pratt & Whitney R-2800-51 Double Wasp |
Power, hp | 2,000 hp |
Power, lbf | Add |
Avionics | Add |
Max cruise speed | 435 km/h |
Approach speed | 113 km/h |
Travel range | 5,074 km |
Fuel economy | Add |
Service ceiling | 7,468 m |
Rate of climb | 5.97 m/sec |
Take off distance | 900 m |
Landing distance | 762 m |
Weights | |
Max take off weight | 21,772 kg |
Max landing weight | 20,412 kg |
Max payload | 6,800 kg |
Fuel tank capacity | 5,322 l |
Baggage volume | Add |
Dimensions | |
Seats | 4 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 2 m |
Cabin width | 3 m |
Cabin length | 14.6 m |
Exterior length | 23.27 m |
Tail height | 6.63 m |
Fuselage diameter | 3.2 m |
Wing span | 32.92 m |
Wing tips | No Winglets |
