Attribute | Value |
---|---|
General | |
Manufacturer | British Aero |
Model | British Aerospace ATP |
Country | United Kingdom |
Manufactured from | 1988 year |
Manufactured to | 1996 year |
Type | Passenger Turbo Props |
Icao | ATP |
Performance | |
Engine | 2x Pratt & Whitney Canada PW126 |
Power, hp | 2,653 hp |
Power, lbf | Add |
Avionics | Add |
Max cruise speed | 496 km/h |
Approach speed | 194 km/h |
Travel range | 1,824 km |
Fuel economy | Add |
Service ceiling | 7,620 m |
Rate of climb | 5.08 m/sec |
Take off distance | 1,460 m |
Landing distance | 1,130 m |
Weights | |
Max take off weight | 23,678 kg |
Max landing weight | 23,133 kg |
Max payload | 8,000 kg |
Fuel tank capacity | 6,363 l |
Baggage volume | Add |
Dimensions | |
Seats | 66 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 1.92 m |
Cabin width | 2.48 m |
Cabin length | 19.2 m |
Exterior length | 26 m |
Tail height | 7.59 m |
Fuselage diameter | 2.95 m |
Wing span | 30.63 m |
Wing tips | No Winglets |
