Attribute | Value |
General |
Manufacturer | Xian |
Model | Xian MA60 |
Country | China |
Manufactured from | 2000 year |
Manufactured to | Add |
Type | Military Propellor Planes |
Icao | MA60 |
Performance |
Engine | 2x Pratt & Whitney Canada PW127J |
Power, hp | 2,750 hp |
Power, lbf | Add |
Avionics | Rockwell Collins Pro-Line 21 |
Max cruise speed | 515 km/h |
Approach speed | Add |
Travel range | 1,593 km |
Fuel economy | Add |
Service ceiling | 7,620 m |
Rate of climb | 7.62 m/sec |
Take off distance | 1,800 m |
Landing distance | 1,600 m |
Weights |
Max take off weight | 21,800 kg |
Max landing weight | 21,600 kg |
Max payload | 5,500 kg |
Fuel tank capacity | 5,602 l |
Baggage volume | Add |
Dimensions |
Seats | 64 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 1.9 m |
Cabin width | 2.7 m |
Cabin length | 10.8 m |
Exterior length | 24.7 m |
Tail height | 8.86 m |
Fuselage diameter | 2.9 m |
Wing span | 29.2 m |
Wing tips | No Winglets |
