Attribute | Value |
---|---|
General | |
Manufacturer | ATR Aircraft |
Model | ATR 42-500 |
Country | France |
Manufactured from | 1994 year |
Manufactured to | Add |
Type | Passenger Turbo Props |
Icao | AT45 |
Performance | |
Engine | 2x 2 X Pratt & Whitney PW127E |
Power, hp | 2,400 hp |
Power, lbf | Add |
Avionics | Dual Honeywell HT1000 FMS |
Max cruise speed | 556 km/h |
Approach speed | 193 km/h |
Travel range | 1,326 km |
Fuel economy | 1.243 km/l |
Service ceiling | 7,620 m |
Rate of climb | 9.4 m/sec |
Take off distance | 1,165 m |
Landing distance | 964 m |
Weights | |
Max take off weight | 18,600 kg |
Max landing weight | 18,300 kg |
Max payload | 5,450 kg |
Fuel tank capacity | 5,602 l |
Baggage volume | 10.8 m³ |
Dimensions | |
Seats | 48 |
Seats - business class | Add |
Seats - first class | Add |
Cabin height | 1.9 m |
Cabin width | 2.57 m |
Cabin length | 9.5 m |
Exterior length | 22.67 m |
Tail height | 7.59 m |
Fuselage diameter | 2.7 m |
Wing span | 24.57 m |
Wing tips | No Winglets |
