Mooney M22 Mustang [+]Compare [E]dit [H]istory
Object «Mooney M22 Mustang» was created due to
Add new object to «Mooney M22 Mustang» or move existing objects here.
Object «Mooney M22 Mustang» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Mooney Aircraft |
| Model | Mooney M22 Mustang |
| Country | United States |
| Manufactured from | 1965 year |
| Manufactured to | 1970 year |
| Type | Private Single Engine |
| Icao | M22 |
| Performance | |
| Engine | 1x Lycoming TIO-541-A1A |
| Power, hp | 310 hp |
| Power, lbf | Add |
| Avionics | Narco 810 , Narco 120/20, Narco 825 connected to HSI, Narco 122, Narco AT 150 Transponder King |
| Max cruise speed | 411 km/h |
| Approach speed | 107 km/h |
| Travel range | 2,402 km |
| Fuel economy | Add |
| Service ceiling | 7,315 m |
| Rate of climb | 5.72 m/sec |
| Take off distance | 348 m |
| Landing distance | 292 m |
| Weights | |
| Max take off weight | 1,670 kg |
| Max landing weight | 1,670 kg |
| Max payload | 564 kg |
| Fuel tank capacity | 348 l |
| Baggage volume | Add |
| Dimensions | |
| Seats | 5 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | Add |
| Cabin width | Add |
| Cabin length | Add |
| Exterior length | 8.23 m |
| Tail height | 3 m |
| Fuselage diameter | 1.4 m |
| Wing span | 10.67 m |
| Wing tips | No Winglets |
