PZL Swidnik SW-4 [+]Compare [E]dit [H]istory
Object «PZL Swidnik SW-4» was created due to
Add new object to «PZL Swidnik SW-4» or move existing objects here.
Object «PZL Swidnik SW-4» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | PZL Swidnik |
| Model | PZL Swidnik SW-4 |
| Country | Poland |
| Manufactured from | 2002 year |
| Manufactured to | Add |
| Type | Light Helicopters |
| Icao | PSW4 |
| Performance | |
| Engine | 1x 1 × Rolls Royce Allison 250-C20R/2 |
| Power, hp | 451 hp |
| Power, lbf | Add |
| Avionics | Add |
| Max cruise speed | 206 km/h |
| Approach speed | Add |
| Travel range | 796 km |
| Fuel economy | 1.932 km/l |
| Service ceiling | 5,212 m |
| Rate of climb | 10.31 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 1,800 kg |
| Max landing weight | Add |
| Max payload | 750 kg |
| Fuel tank capacity | 471 l |
| Baggage volume | Add |
| Dimensions | |
| Seats | 4 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.27 m |
| Cabin width | 1.41 m |
| Cabin length | 2.14 m |
| Exterior length | 10.57 m |
| Tail height | 3.14 m |
| Fuselage diameter | 1.6 m |
| Wing span | 9 m |
| Wing tips | No Winglets |
