Eurocopter EC135 [+]Compare [E]dit [H]istory
Object «Eurocopter EC135» was created due to
Add new object to «Eurocopter EC135» or move existing objects here.
Object «Eurocopter EC135» has attributes [Show empty attributes][Hide empty attributes]
| Attribute | Value |
|---|---|
| General | |
| Manufacturer | Eurocopter |
| Model | Eurocopter EC135 |
| Country | France |
| Manufactured from | 1995 year |
| Manufactured to | Add |
| Type | Mid Size Helicopters |
| Icao | EC35 |
| Performance | |
| Engine | 2x Turbomeca Arrius 2B2 |
| Power, hp | 633 hp |
| Power, lbf | Add |
| Avionics | Avionique Nouvelle glass cockpit, Helionix Avionics |
| Max cruise speed | 254 km/h |
| Approach speed | Add |
| Travel range | 635 km |
| Fuel economy | 1.081 km/l |
| Service ceiling | 6,096 m |
| Rate of climb | 7.62 m/sec |
| Take off distance | Add |
| Landing distance | Add |
| Weights | |
| Max take off weight | 2,910 kg |
| Max landing weight | Add |
| Max payload | 1,455 kg |
| Fuel tank capacity | 708 l |
| Baggage volume | 1.1 m³ |
| Dimensions | |
| Seats | 8 |
| Seats - business class | Add |
| Seats - first class | Add |
| Cabin height | 1.26 m |
| Cabin width | 1.5 m |
| Cabin length | 3.5 m |
| Exterior length | 12.16 m |
| Tail height | 3.51 m |
| Fuselage diameter | 1.56 m |
| Wing span | 10.2 m |
| Wing tips | No Winglets |
